Allnic Audio T-1800 Mk2 Integrated Amplifier - Consignment
Condition: Used. Excellent, small chips on remote only (See photos)
Includes: Remote, Manual, Original box
SN: 25358
Made In Korea
Overview
The Allnic Audio T-1800 MK2 is a stereo integrated valve amplifier delivering 40 watts per channel through a push-pull EL34 output stage.
Its design incorporates Allnic’s use of Permalloy, an iron-nickel alloy, in transformer cores, alongside large 96mm nickel/FeSi-core output transformers. The transformer design uses Allnic’s “Full Engagement” configuration, in which all four independent secondary windings remain connected rather than leaving unused windings idle.
The amplification circuit uses two stages of driver circuitry, comprising two E180CC valves and one 12AY7 valve, with the EL34s forming the output stage, and supports 4- and 8-ohm loudspeaker loads.
A custom 41-step, remote-controlled attenuator with silver contacts provides volume adjustment, replacing a conventional carbon-film potentiometer.
The amplifier also incorporates self-biasing circuitry and individual analogue current monitoring for the output valves, allowing their operating status to be checked directly from the front panel. A soft-start circuit delays the application of high voltage until the valves have warmed up.
RCA preamplifier outputs allow connection to an external powered subwoofer.
Specification
Output Power 40w + 40w (4 or 8 load, at 1kHz)
Distortion 0.1% at 1kHz at 2.83V
Frequency Response 20Hz-20kHz flat
S/N Ratio -80dB (CCIR, 1kHz)
Damping Factor 8 at 8Ω load at 1kHz
Voltage gain +38dB
Input Impedance 10kΩ (single-ended, unbalanced)
Input Sensitivity 400mV for rated power
Tubes EL34 x 4 (power triode); E180CC x 2 (2nd stage driver tube: similar to 5965 and 7062); 12AY7 x 1 (1st stage driver: possible to substitute 6072)
Dimensions(WDH) 430mm x 330mm x 210mm
Weight 20kg net; 23kg shipping
AUDIO CONNECTION QUALITY GUARANTEE
✔️ Seven day warranty on Consignment*
✔️Passed our checks for functionality
✔️A full inspection noting for any defects
✔️A full completeness check for all included parts and accessories
